Master Dual Voltage Indirect Diesel Oil Heater BV170DV
Dual Voltage | 160,400 Btu | 47 kW | 65 Litre Tank | Diesel or HVO 100 Biofuel
Indirect heaters are highly efficient and provide 100% clean, dry and fume free air. They are best used where there is limited ventilation in the space you are looking to heat such as warehouses, exhibition halls and marquees to name but a few.
The Indirect heater is placed outside where the exhaust fumes are vented through a vertical exhaust pipe into the open air.
The Master range of indirect heaters range from 20kW or 116,000 Btu to 225kW or 768,000 Btu and are available in 110, 240 Volt or Dual voltage dependent on the model.
Complemented by a full range of accessories including digital thermostats, ducting kits and exhausts there is a package for most indirect heating requirements.
Depending on the space you are looking to heat will depend on the size of your heater.
If you require any further technical advice regarding the right heater for the right job do not hesitate to contact any member of our sales team
-
BV170DV Parts Drawing 2013 Size: (952.77 KB)
-
BV170DV Parts Drawing 2013 Serial Number Range 233002474 To 234000387 Size: (996.1 KB)
-
BV170DV Parts Drawing 2014 Serial Number Range 234000388 To 09234001978 Size: (974.55 KB)
-
BV170DV Parts Drawing 2022 Serial Number Range 11242000001 Size: (1.04 MB)
-
BV170DV Specification Sheet Size: (1.37 MB)
-
BV170DV User Manual Size: (4.97 MB)
Fuel Type : | Diesel Oil or HVO 100 Biofuel |
Voltage : | Dual Voltage 110 or 240 Volt |
Heating Power (Kw) : | 49 Kw |
Heating Power (Btu) : | 167,200 Btu |
Heating Power (Kcal) : | 42,100 Kcal |
Thermostat Control : | Analog (Optional Extra) |
Thermostat Control : | Digital (Optional Extra) |
Air Displacement : | 1,800 M3/h |
Air Pressure : | 10 Bar |
Fan Type : | Axial |
Power : | 800 Watts |
Rated Current : | 3.5 Amp |
Fuel Tank Capacity : | 65 Litres |
Fuel Consumption : | 4.7 Litres Per Hour |
IP Rating : | IP44 |
Air Outlet Diametre (Single) : | 1 x 34cm (Standard) |
Air Outlet Diametre (2 Way) : | 2 x 31cm Splitter (Optional Extra) |
Air Outlet Diametre (4 Way) : | Not Available |
Ducting Diametre (Single) : | 34cm (Standard) |
Ducting Diametre (2 Way) : | 34cm 2 Way Splitter |
Ducting Diametre (4 Way) : | Not Available |
Ducting : | Optional Extra |
Exhaust Tube Diametre : | 15cm |
Exhaust x 1 Metre : | Optional Extra |
Exhaust Rain Lid : | Optional Extra |
Length : | 135cm |
Width : | 57.5cm |
Height : | 100cm |
Forklift Slots : | Not Available |
Trolley Wheel Kit : | Included |
Noise Level : | 78 db(A) |
Weight : | 67kg |
